E P Series
2 & 3 Jaws Combination Pullers
Capacity: 4 - 30 Ton
Max. Reach: 185 - 360mm
Max Spread: 255 - 550mm
• Self-contained hydraulic pump & puller body with integral safety valve for overloading protection.
• 2/3 jaws combination puller cross head plated for corrosion resistance and durability.
• Removable & foldable 4-stage handle.
• 360° rotary handle socket for all directional pumping.
• Easily release control valve.
• Removable spring-loaded live centring cone for easy positioning.
• Heat-treated & chrome-plated hydraulic cylinder rod provides linear force.
• Optional extension rods allow user to extend the stroke according to requirement.
• Supplied with sturdy carrying case.
• Ideal for removing gears, bearings, bushings, pulleys & other press-fitted parts.
