Hydraulic Pullers


EPRB100-1
100T Roller Bearing Push-Puller

CAPACITY:
100 Ton (Pulling)
68 Ton (Installing)
STROKE:
392 mm
1.12 kW (220V/50-60Hz/1ph)
(Railroad Version)

FEATURES

• Designed for quick removal or installation of axle journal
  tapered roller bearings.
• Specially designed for the major bearing manufacturers.
• Simple, efficient, easy to use and reliable operation provided
  with 100 Ton pulling force.
• Portable design for easy, convenient positioning and saving
  storage space.
• Cart with swivel castors provide easy mobility.
• Basic equipment used in most rolling stock maintenance in
  railway shops.

Equipped with

• Two-stage hydraulic pump.
• 1.12 kW, 220V/50-60Hz/1ph universal brushless motor
  (3-phase version available on request).
• Pressure gauge, 100mm dial dia.
• Manual control & safety relief valve.
  (Available option with solenoid control valve)
• 3m remote hand control pendant switch (24VAC).
• Hydraulic lift system for easy positioning of puller.
